Dahua DH-XVR1B08 User Manual

Local Configurations 113
Figure 5-72
Configure the settings for the text overlay parameters. See Table 5-26. Step 2
Parameter
Description
Channel
In the Channel list, select the channel that you want to configure the
settings for.
Time Display
Select the Time Display check box to display the system time on
each channel window in the live view screen.
In the Time Display list, select time display style.
Channel Title
Select the Channel Title check box to display the channel name on
each channel window in the live view screen.
In the Channel Title box, enter the name for the selected channel.
Table 5-26
Click Apply to complete the settings. Step 3
Click Copy to copy the settings to other channels.
5.5.4 Configuring Covered Area Settings
Select Main Menu > CAMERA > OVERLAY > Cover-Area. Step 1
The Cover-Area interface is displayed. See Figure 5-73.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
