Local Configurations 307
Figure 5-281
Status
Battery
Capacity
Above 60%
30%60%
Below 30%
Charging
Charging
completed
Table 5-81
5.20.9 Viewing PoC Information
Not all models support this function.
You can view the information about PoC camera, such as quantity, mode, and power
consumption.
Select Main Menu > CAMERA > PoC INFO, the PoC INFO interface is displayed. See Figure
5-282.
Figure 5-282
Parameter
Description
AF
The maximum power of PoC camera is 6 W.
AT
The maximum power of PoC camera is 12 W.
--
Non PoC camera or no camera is connected.
Table 5-82

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua DH-XVR1B08 and is the answer not in the manual?

Dahua DH-XVR1B08 Specifications

General IconGeneral
Audio Input1 channel, RCA
Audio Output1 channel, RCA
Video Output1 HDMI, 1 VGA
USB2 USB 2.0 ports
Power SupplyDC12V/1.5A
Video CompressionH.265/H.264
Analog Camera Input8 channels, BNC
IP Camera Input8
HDD1 SATA port, up to 6TB
Network1 RJ-45 port (10/100 Mbps)
Operating Temperature-10°C to +55°C
Operating Humidity10% to 90%
Max Recording Resolution1080N/720p/960H/D1/CIF
