Dahua DH-XVR1B08 User Manual

Local Configurations 129
Figure 5-91
5.6.2.2 Viewing Firmware Information
You can view the device firmware information such as channel number, IP address,
manufacturer, system version, video input, audio input, and alarm in.
Select Main Menu > CAMERA > REGISTRATION > Firmware, the Firmware interface is
displayed. See Figure 5-92.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
