Dahua DH-XVR1B08 User Manual

Local Configurations 205
Figure 5-167
In the Channel list, select the channel that you want to search for the events. Step 2
In the Type list, select the event type that you want to search. Step 3
In the Begin Time box and End Time box, enter the date and time.
Step 4
Select the display mode of the search results by clicking Graph or List. Step 5
Click Search. Step 6
The results that satisfy the searching conditions are displayed. See Figure 5-168 and
Figure 5-169.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
