Dahua DH-XVR1B08 User Manual

Local Configurations 243
Figure 5-205
Configure the settings for the UPnP parameters. See Table 5-65. Step 2
Parameter
Description
PAT
Enable the UPnP function.
Status
Indicates the status of UPnP function.
Offline: Failed.

Online: Succeeded.

LAN IP
Enter IP address of router on the LAN.
After mapping succeeded, the system obtains IP address
automatically without performing any configurations.
WAN IP
Enter IP address of router on the WAN.
After mapping succeeded, the system obtains IP address
automatically without performing any configurations.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
