Dahua DH-XVR1B08 User Manual

Local Configurations 282
Figure 5-256
Configure the settings for the FTP settings parameters. See Table 5-75. Step 2
Parameter
Description
Enable
Enable the FTP upload function.
FTP type
Select FTP type.
FTP: Plaintext transmission.

SFTP: Encrypted transmission (recommended)

Server
IP address of FTP server.
Port
FTP: The default is 21.

SFTP: The default is 22.

Anonymity
Enter the user name and password to login the FTP server.
Enable the anonymity function, and then you can login
anonymously without entering the user name and password.
User Name
Password
Remote Directory
Create folder on FTP server.
If you do not enter the name of remote directory, system

automatically creates the folders according to the IP and
time.
If you enter the name of remote directory, the system creates

the folder with the entered name under the FTP root
directory first, and then automatically creates the folders
according to the IP and time.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
