Dahua DH-XVR1B08 User Manual

Local Configurations 298
Figure 5-272
In the Type list, select the log type that you want to view (System, Config, Storage, Step 2
Record, Account, Clear, Playback, and Connection) or select All to view all logs.
In the Start Time box and End Time box, enter the time period to search, and then
Step 3
click Search.
The search results are displayed. See Figure 5-273.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
