Dahua DH-XVR1B08 User Manual

Local Configurations 58
Figure 5-18
 If you select the Auto-check for updates check box, the system will notify you
automatically when updates are available.
 After the auto-check function is enabled, to notify you to update timely, the system will
collect the information such as IP address, device name, firmware version, and device
serial number. The collected information is only used to verify the legality of the Device and
push upgrade notices.
 If you clear the Auto-check for updates check box, the system will not perform automatic
checks.
5.1.4.2 Configuring General Settings
You can configure the general settings for the Device such as Device name, language, and
settings for instant playback.
You can also configure general settings by selecting Main Menu > SYSTEM > GENERAL >
General.
On the Startup Wizard interface, click Next. Step 1
The General interface is displayed. See Figure 5-19.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
