Local Configurations 62
Figure 5-21
Configure the settings for network parameters. See Table 5-5. Step 2
Parameter
Description
Net Mode
Multi-address: Two Ethernet ports work separately through either
of which you can request the Device to provide the services such
as HTTP and RTSP. You need to configure a default Ethernet port
(usually the Ethernet port 1 by default) to request the services from
the device end such as DHCP, Email and FTP. If one of the two
Ethernet ports is disconnected as detected by networking testing,
the system network status is regarded as offline.
Fault Tolerance: Two Ethernet ports share one IP address.
Normally only one Ethernet port is working and when this port fails,
the other port will start working automatically to ensure the network
connection.
When testing the network status, the network is regarded as offline
only when both of the two Ethernet ports are disconnected. The
two Ethernet ports are used under the same LAN.
Load Balance: Two network cards share one IP address and they
are working at the same time to share the network load averagely.
If one of them fails, the other can continue working normally.
When testing the network status, the network is regarded as offline
only when both of the two Ethernet ports are disconnected. The
two Ethernet ports are used under the same LAN.
The Device with single Ethernet port does not support this function.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua DH-XVR1B08 and is the answer not in the manual?

Dahua DH-XVR1B08 Specifications

General IconGeneral
Audio Input1 channel, RCA
Audio Output1 channel, RCA
Video Output1 HDMI, 1 VGA
USB2 USB 2.0 ports
Power SupplyDC12V/1.5A
Video CompressionH.265/H.264
Analog Camera Input8 channels, BNC
IP Camera Input8
HDD1 SATA port, up to 6TB
Network1 RJ-45 port (10/100 Mbps)
Operating Temperature-10°C to +55°C
Operating Humidity10% to 90%
Max Recording Resolution1080N/720p/960H/D1/CIF
