User's Manual
107
Table 5-7 Icon description
No. Icon Description
1
The current channel is recording.
2
Motion detection alarm occurs.
3
Video loss alarm occurs.
4
The current channel is in monitor lock status.
5
The Device connects to the network camera remotely.
This function is available on select models.
5.6.2 Navigation bar
You can quickly perform operations through the icons on the navigation bar.
The navigation bar might vary with models.
Step 1 After login, right-click the live page, and then select
Main Menu
.
Step 2 Select
System
>
General
>
Basic
.
Step 3 Click to enable navigation bar.
Step 4 On the live page, click any position and then the navigation appears at the bottom.
Figure 5-14 Navigation bar
Table 5-8 Navigation bar description
Icon Function
Open
Main Menu
.
Expand or condense the navigation bar.
Select view layout.
Go to the previous screen.
Go to the next screen.
Enable tour function. The icon switches to .
If you close the tour or the triggered tour operation has canceled,
the Device restores the previous preview video.
Open the PTZ control panel. For details, see "5.6.7.2 PTZ Control".
Configure image settings. For details, see "5.7.4 Configuring
Image Settings".
This function is supported only in single-channel layout.
Search for records. For detail, see "5.8.2.1 Search Page".
Open the
Voice Broadcast
page. For detail, see"5.18.3 Broadcast".
