Figure 3-31 Unlock front panel

Step 5 Close the front panel and then tighten the lock on the front panel.

Figure 3-32 Lock front panel

3.3.6 NVR616-4KS2 Series

The following figures are for reference only.

Procedure

Step 1 Press the red button on the HDD box, open the handle and then pull out the HDD box.

Figure 3-33 Take out HDD box

Step 2 Put the HDD into the HDD box along the direction shown in the following arrow.

Foreword2
