Dahua JRC-27F - Front Panel and Rear Panel; Front Panel; NVR41-4 KS2;NVR41-P-4 KS2;NVR41-8 P-4 KS2;NVR41-4 KS2;L;NVR41-P-4 KS2;L;NVR41-8 P- 4 KS2;L;NVR21-4 KS2;NVR21-P-4 KS2;NVR21-8 P-4 KS2;NVR21-S3;NVR21-P-S3;NVR21-8 P-S3 Series

User's Manual
4
2 Front Panel and Rear Panel
The following front panel and rear panel figures are for reference only.
2.1 Front Panel
2.1.1 NVR41-4KS2/NVR41-P-4KS2/NVR41-8P-4KS2/NVR41-
4KS2/L/NVR41-P-4KS2/L/NVR41-8P-4KS2/L/NVR21-4KS2/NVR21-P-
4KS2/NVR21-8P-4KS2/NVR21-S3/NVR21-P-S3/NVR21-8P-S3 Series
The figure is for reference only.
The NVR41-4KS2/NVR41-4KS2/L/NVR41-P-4KS2/NVR41-P-4KS2/L/NVR21-4KS2/NVR21-P-
4KS2/NVR21-S3/NVR21-P-S3 front panel is shown as below.
Figure 2-1 Front panel
The NVR41-8P-4KS2/NVR41-8P-4KS2/L/NVR21-8P-4KS2/NVR21-8P-S3 front panel is shown as below.
