User's Manual
239
Figure 5-152 People counting
Step 2 Select a channel and then click
Add
.
Step 3 Select the
Enable
checkbox and then set
Type
to
In Area No.
Step 4 Draw people counting rule.
1) Click to draw a rule. Right-click the image to stop drawing.
2) Configure the parameters.
3) Click
OK
.
Step 5 Click and then enable in-area people number alarm and stay alarm.
Step 6 Click under
Trigger
to configure the alarm schedule and linkage
Step 7 Click
Apply
.
5.9.11.4 Queuing
After configuring queuing alarm, the system can realize the corresponding linkage actions once the
number of people in the queue or the waiting time has triggered an alarm.
Step 1 Select
Main Menu
>
AI
>
Parameters
>
People Counting
>
Queuing
.
