User's Manual
290
Parameter Description
IP Address
Enter the IP address that you want to use as the multicast IP.
The IP address ranges from 224.0.0.0 through 239.255.255.255.
Port
Enter the port for the multicast. The port ranges from 1025 through
65000.
Step 3 Click
Apply
.
You can log in to the web interface via multicast.
On the web login page, on the
Type
list, select
Multicast
. The web will automatically
obtain the multicast IP address and join the multicast group. Then you can view the video
through multicast function.
5.11.15 Alarm Center
You can configure the alarm center server to receive the uploaded alarm information.
Procedure
Step 1 Select
Main Menu
>
NETWORK
>
Alarm Center
.
Figure 5-200 Alarm center
Step 2 Click to enable the function.
Step 3 Configure the parameters.
Table 5-62 Alarm center parameters
Parameter Description
Protocol Type Select a protocol type.
Server Address
The IP address and communication port of the PC installed with alarm
