Figure 2-9 Front panel
The NVR21-P-I/NVR21-P-I2 front panel is shown as below.
Figure 2-10 Front panel
The NVR21-8P-I/NVR21-8P-I2 front panel is shown as below.
Figure 2-11 Front panel
2.1.7 NVR22-I/NVR22-I2/NVR22-P-I/NVR22-P-I2/NVR22-8P-I/NVR22-
8P-I2/NVR22-16P-I/NVR22-16P-I2 Series
The figure is for reference only.
The NVR22-I/NVR22-I2 front panel is shown as below.
Figure 2-12 Front panel
The NVR22-P-I/NVR22-P-I2 front panel is shown as below.
Figure 2-13 Front panel
The NVR22-8P-I/NVR22-8P-I2 front panel is shown as below.
