User's Manual

120

Figure 5-28 Split track

Step 2 Select a split mode.

Figure 5-29 Split mode

Split mode includes full screen, 1 main screen + 3 split screens and 1 main screen + 5 split

screens.

●

You can move the rectangles with color to adjust the videos displayed on split screens.

●

You can scroll the mouse in split screens to zoom in or out the video.
