Figure 5-31 PTZ (local)

Figure 5-32 PTZ (remote)

Step 2 Configure parameters.

Table 5-11 PTZ parameters

Parameter Description

Channel Select the channel that you want to connect the PTZ camera to.

Type

●

Local: Connect through RS-485 port.

●

Remote: Connect through network by adding IP address of PTZ camera

to the Device.
