User's Manual
200
Figure 5-115 Abandoned object rule
2) Click to draw the minimum size or maximum size to filter the target.
The system triggers an alarm only when the size of detected target is between the
maximum size and the minimum size.
3) Configure parameters.
Table 5-30 Parameters of abandoned object detection
Parameter Description
Preset Select a preset you want to use IVS.
Name Customize the rule name.
Duration
The system generates an alarm once the object is in the zone for the
defined period.
4) Click
OK
.
Step 6 Configure alarm schedule and linkage.
