No. Port Name Function
4 HDMI port
High definition audio and video signal output port. It transmits
uncompressed high definition video and multiple-channel
audio data to displays with HDMI port. The two HDMI ports
support 2-channel high definition HDMI output of different
sources.
5 VGA port
VGA video output port. Output analog video signal. It can
connect to the monitor to view analog video.
6 RS-232 port
It is for general COM debugging to configure IP address and
transfer transparent COM data.
7
Alarm input port (1-
16)
●
There are four groups: 1-4, 5-8, 9-12 and 13-16.
They receive signals from external alarm source. Alarm
input includes two types; NO (normal open) and NC (normal
close).
●
When your alarm input device is using external power,
make sure the device and the NVR have the same GND.
Alarm output port
(NO1-NO5, C1-C5,
NC5)
●
Five groups of alarm output ports (Group 1: NO1-C1, Group
2: NO2-C2, Group 3: NO3-C3, Group 4: NO4-C4, Group 5:
NO5, C5, NC5). Output alarm signal to the external alarm
device. Make sure power supply is available for the external
alarm device.
●
NO: Normal open alarm output port.
●
C: Alarm output public end.
●
NC: Normal close alarm output port.
GND. Alarm input ground port.
RS-485 port (A, B)
●
RS485_A port. Control cable A of the 485 device. It connects
external devices such as speed dome and PTZ.
●
RS485_B port. Control cable B of the 485 device. It connects
external devices such as speed dome and PTZ.
CTRL
Controllable 12 V power output. It is
to control the on-off alarm relay
output. It can be used to control the
device alarm output. At the same
time, it can also be used as the power
input source of some devices such as
alarm detector.
The two ports serve
as another group of
alarm output ports.
+12 V power output port. It can
provide power to some peripheral
devices such as camera and alarm
device. Make sure the power supply of
peripheral device shall be below 1 A.
8 MIC IN
Bidirectional talk input port. It is to receive analog audio signal
from devices such as microphone, sound pickup.
