User's Manual
53
No. Port Name Function
Alarm
output port
(NO1, C1)
●
One group of alarm output ports (Group 1:
NO1-C1). Output alarm signal to the external
alarm device. Make sure power supply is
available for the external alarm device.
●
NO: Normal open alarm output port.
●
C: Alarm output public end.
GND. Alarm input ground port.
CTRL
Controllable 12 V power
output. It is to control the
on-off alarm relay output. It
can be used to control the
device alarm output. At the
same time, it can also be
used as the power input
source of some devices
such as alarm detector.
The two ports
serve as another
group of alarm
output ports.
P
+12 V power output port. It
can provide power to some
peripheral devices such as
camera and alarm device.
Make sure the power supply
of peripheral device shall be
below 1 A.
5 HDMI port
High definition audio and video signal output port. It transmits
uncompressed high definition video and multiple-channel audio
data to displays with HDMI port.
6 USB port
USB 3.0 port. Connect to devices such as mouse, USB storage
device and USB burner.
7 Network port
10/100/1000 Mbps self-adaptive Ethernet port. Connect to the
network cable.
8
MIC IN
Bidirectional talk input port. It is to receive analog audio signal
from devices such as microphone, sound pickup.
MIC OUT
Audio output port. It is to output analog audio signal to devices
such as sound box.
●
Bidirectional talk output.
●
Audio output on 1-window video monitor.
●
Audio output on 1-window video playback.
9 VGA port
VGA video output port. Output analog video signal. It can
connect to the monitor to view analog video.
10 RS-232 port
It is for general COM debugging to configure IP address and
transfer transparent COM data.
11
GND.
