Danfoss VLT AQUA Drive FC 202 Programming Guide

Safety regulations
•
Disconnect the mains supply to the frequency
converter whenever repair work is to be carried
out. Check that the mains supply has been
disconnected and that the necessary time has
elapsed before removing motor and mains supply
plugs. For information about the discharge time,
see Table 1.2.
•
[O] does not disconnect the mains supply and
therefore, it must not be used as a safety switch.
•
Ground the equipment properly. Protect the user
against supply voltage and protect the motor
against overload in accordance with applicable
national and local regulations.
•
The ground leakage current exceeds 3.5 mA.
•
Protection against motor overload is not included
in the factory setting. If this function is required,
set parameter 1-90 Motor Thermal Protection to
data value [4] ETR trip 1 or data value [3] ETR
warning 1.
•
Do not remove the plugs for the motor and
mains supply while the frequency converter is
connected to mains. Check that the mains supply
has been disconnected and that the necessary
time has elapsed before removing motor and
mains plugs.
•
The frequency converter has more voltage
sources than L1, L2, and L3, when load sharing
(linking of DC-link) or
external 24 V DC is installed. Check that all
voltage sources have been disconnected and that
the necessary time has elapsed before
commencing repair work. For information about
the discharge time, see Table 1.2.
WARNING
UNINTENDED START
When the frequency converter is connected to AC mains,
DC supply, or load sharing, the motor may start at any
time. Unintended start during programming, service, or
repair work can result in death, serious injury, or
property damage. The motor can start via an external
switch, a eldbus command, an input reference signal
from the LCP, or after a cleared fault condition.
To prevent unintended motor start:
•
Disconnect the frequency converter from the
mains.
•
Press [O/Reset] on the LCP before
programming parameters.
•
Completely wire and assemble the frequency
converter, motor, and any driven equipment
before connecting the frequency converter to
AC mains, DC supply, or load sharing.
WARNING
DISCHARGE TIME
The frequency converter contains DC-link capacitors,
which can remain charged even when the frequency
converter is not powered. High voltage can be present
even when the warning LED indicator lights are o.
Failure to wait the specied time after power has been
removed before performing service or repair work can
result in death or serious injury.
•
Stop the motor.
•
Disconnect AC mains and remote DC-link power
supplies, including battery back-ups, UPS, and
DC-link connections to other frequency
converters.
•
Disconnect or lock PM motor.
•
Wait for the capacitors to discharge fully. The
minimum waiting time is specied in Table 1.2
and is also visible on the nameplate on top of
the frequency converter.
•
Before performing any service or repair work,
use an appropriate voltage measuring device to
make sure that the capacitors are fully
discharged.
Voltage [V]
Minimum waiting time (minutes)
4 7 15
200–240 0.25–3.7 kW
(0.34–5 hp)
– 5.5–45 kW
(7.5–60 hp)
380–480 0.37–7.5 kW
(0.5–10 hp)
– 11–90 kW
(15–121 hp)
525–600 0.75–7.5 kW
(1–10 hp)
– 11–90 kW
(15–121 hp)
525–690 – 1.1–7.5 kW
(1.5–10 hp)
11–90 kW
(15–121 hp)
Table 1.2 Discharge Time
Introduction
VLT
®
AQUA Drive FC 202
8 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
