6-73 Terminal X45/1 Bus Control
Enter the output value for terminal X45/1 when the eldbus
controls the terminal.
Range: Function:
0 %* [0 - 100 %]
6-74 Terminal X45/1 Output Timeout Preset
Enter the output value for terminal X45/1 when the bus control
timeout for the terminal is detected.
Range: Function:
0 %* [0 - 100 %]
6-80 Terminal X45/3 Output
Select the output of terminal X45/3 of VLT
®
Extended Relay Card
MCB 113.
Option: Function:
[0] * No operation
[52] MCO 0-20mA/0-10V
[53] MCO 4-20mA
[100] Output freq. 0-100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[108] Torque +-160%
[109] Out frq 0-Fmax
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[116] Cascade Reference
[117] Shaft Power
[118] Shaft Power 4-20mA
[130] Out frq 0-100 4-20mA
[131] Reference 4-20mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20mA
[134] Torq.0-lim 4-20 mA
[135] Torq.0-nom 4-20mA
[136] Power 4-20mA
[137] Speed 4-20mA
[138] Torque 4-20mA
[139] Bus ctrl.
[140] Bus ctrl. 4-20 mA
[141] Bus ctrl t.o.
[142] Bus ctrl t.o. 4-20mA
[143] Ext. CL 1 4-20mA
[144] Ext. CL 2 4-20mA
[145] Ext. CL 3 4-20mA
[146] Cascade Ref. 4-20mA
[147] Main act val 0-20mA
[148] Main act val 4-20mA
6-80 Terminal X45/3 Output
Select the output of terminal X45/3 of VLT
®
Extended Relay Card
MCB 113.
Option: Function:
[150] Out frq 0-Fmax 4-20mA
[156] Flow Rate
[157] Flow Rate 4-20mA
[254] DC Link 0-20mA
[255] DC Link 4-20mA
6-81 Terminal X45/3 Min. Scale
Enter the minimum scaling value of output of the analog signal
on terminal X45/3.
Range: Function:
0 %* [0 - 200 %]
6-82 Terminal X45/3 Max. Scale
Enter the maximum scaling value of output of the analog signal
on terminal X45/3.
Range: Function:
100 %* [0 - 200 %]
6-83 Terminal X45/3 Bus Control
Enter the output value for terminal X45/3 when the eldbus
controls the terminal.
Range: Function:
0 %* [0 - 100 %]
6-84 Terminal X45/3 Output Timeout Preset
Enter the output value for terminal X45/3 when the bus control
timeout for the terminal is detected.
Range: Function:
0 %* [0 - 100 %]
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 99
