8-17 Congurable Alarm and Warningword

Array [16]

Select the meaning of a specic bit in the congurable alarm

and warning word. The word has 16 bits (0–15).

Option: Function:

[9] Inverter overloaded warning

[10] Motor ETR overtemp warning

[11] Motor thermistor overtemp warning

[12] Torque limit warning

[13] Over current warning

[14] Earth fault warning

[17] Controlword timeout warning

[19] Discharge temp high warning

[23] Internal fans warning

[24] External fans warning

[25] Brake resistor short circuit warning

[26] Brake powerlimit warning

[27] Brake chopper short circuit warning

[28] Brake check warning

[29] Heatsink temperature warning

[30] Motor phase U warning

[31] Motor phase V warning

[32] Motor phase W warning

[34] Fieldbus communication warning

[36] Mains failure warning

[40] T27 overload warning

[41] T29 overload warning

[45] Earth fault 2 warning

[47] 24V supply low warning

[58] AMA internal fault warning

[59] Current limit warning

[60] External interlock warning

[61] Feedback error warning

[62] Frequency max warning

[64] Voltage limit warning

[65] Controlboard overtemp warning

[66] Heatsink temp low warning

[68] Safe stop warning

[73] Safe stop autorestart warning

[76] Power unit setup warning

[77] Reduced powermode warning

[163] ATEX ETR cur limit warning

[165] ATEX ETR freq limit warning

[10002] Live zero error alarm

[10004] Mains phase loss alarm

[10007] DC overvoltage alarm

[10008] DC undervoltage alarm

[10009] Inverter overload alarm

[10010] ETR overtemperature alarm

[10011] Thermistor overtemp alarm

[10012] Torque limit alarm

[10013] Overcurrent alarm

[10014] Earth fault alarm

[10016] Short circuit alarm

8-17 Congurable Alarm and Warningword

Array [16]

Select the meaning of a specic bit in the congurable alarm

and warning word. The word has 16 bits (0–15).

Option: Function:

[10017] CTW timeout alarm

[10026] Brake powerlimit alarm

[10027] Brakechopper shortcircuit alarm

[10028] Brake check alarm

[10029] Heatsink temp alarm

[10030] Phase U missing alarm

[10031] Phase V missing alarm

[10032] Phase W missing alarm

[10033] Inrush fault alarm

[10034] Fieldbus com faul alarm

[10036] Mains failure alarm

[10037] Phase imbalance alarm

[10038] Internal fault

[10039] Heatsink sensor alarm

[10045] Earth fault 2 alarm

[10046] Powercard supply alarm

[10047] 24V supply low alarm

[10048] 1.8V supply low alarm

[10049] Speed limit alarm

[10060] Ext interlock alarm

[10061] Feedback error alarm

[10063] Mech brake low alarm

[10065] Controlboard overtemp alarm

[10067] Option cong changed alarm

[10068] Safe stop alarm

[10069] Powercard temp alarm

[10073] Safestop auto restart alarm

[10074] PTC thermistor alarm

[10079] Illegal PS cong alarm

[10081] CSIV corrupt alarm

[10082] CSIV param error alarm

[10090] Feedback monitor alarm

[10091] AI54 settings alarm

[10164] ATEX ETR current lim alarm

[10166] ATEX ETR freq limit alarm

3.9.3 8-3* FC Port Settings

8-30 Protocol

Option: Function:

Protocol selection for the integrated FC

(standard) port (RS485) on the control card.

[0] FC Communication according to the FC protocol

as described in RS485 Installation and Set-up in

the relevant design guide.

[1] FC MC Same as [0] FC but to be used when

downloading SW to the frequency converter or

uploading dll le (covering information

Parameter Description
