Danfoss VLT AQUA Drive FC 202 Programming Guide

8-13 Congurable Status Word STW
This parameter enables conguration of bits 12–15 in the status
word.
Array [16]
Option: Function:
[72] Logic Rule 2 See parameter group 13-4* Logic Rules. If
logic rule 2 is evaluated as true, the
output goes high. Otherwise, it is low.
[73] Logic Rule 3 See parameter group 13-4* Logic Rules. If
logic rule 3 is evaluated as true, the
output goes high. Otherwise, it is low.
[74] Logic Rule 4 See parameter group 13-4* Logic Rules. If
logic rule 4 is evaluated as true, the
output goes high. Otherwise, it is low.
[75] Logic Rule 5 See parameter group 13-4* Logic Rules. If
logic rule 5 is evaluated as true, the
output goes high. Otherwise, it is low.
[80] SL digital out A See parameter 13-52 SL Controller Action.
The output goes high whenever the
smart logic action [38] Set digital out A
high is executed. The output goes low
whenever the smart logic action [32] Set
digital out A low is executed.
[81] SL digital out B See parameter 13-52 SL Controller Action.
The output goes high whenever the
smart logic action [39] Set digital out B
high is executed. The output goes low
whenever the smart logic action [33] Set
digital out B low is executed.
[82] SL digital out C See parameter 13-52 SL Controller Action.
The output goes high whenever the
smart logic action [40] Set digital out C
high is executed. The output goes low
whenever the smart logic action [34] Set
digital out C low is executed.
[83] SL digital out D See parameter 13-52 SL Controller Action.
The output goes high whenever the
smart logic action [41] Set digital out D
high is executed. The output goes low
whenever the smart logic action [35] Set
digital out D low is executed.
[84] SL digital out E See parameter 13-52 SL Controller Action.
The output goes high whenever the
smart logic action [42] Set digital out E
high is executed. The output goes low
whenever the smart logic action [36] Set
digital out E low is executed.
[85] SL digital out F See parameter 13-52 SL Controller Action.
The output goes high whenever the
smart logic action [43] Set digital out F
high is executed. The output goes low
whenever the smart logic action [37] Set
digital out F low is executed.
8-13 Congurable Status Word STW
This parameter enables conguration of bits 12–15 in the status
word.
Array [16]
Option: Function:
[86] ATEX ETR cur.
alarm
[87] ATEX ETR freq.
alarm
[88] ATEX ETR cur.
warning
[89] ATEX ETR freq.
warning
[181] Prev.
Maintenance
[182] Deragging
[183] Post/Pre Lube
[190] No-Flow
[191] Dry Pump
[192] End Of Curve
[193] Sleep Mode
[194] Broken Belt
[196] Emergency
Mode
[197] Emerg. Mode
was Act.
[199] Pipe Filling
[200] User Dened
Alerts
8-14 Congurable Control Word CTW
Array [15]
Option: Function:
[0] None The frequency converter ignores the
information in this bit.
[1] * Prole
default
The functionality of the bit depends on the
selection parameter 8-10 Control Word Prole.
[2] CTW Valid,
active low
If set to 1, the frequency converter ignores
the remaining bits of the control word.
8-17 Congurable Alarm and Warningword
Array [16]
Select the meaning of a specic bit in the congurable alarm
and warning word. The word has 16 bits (0–15).
Option: Function:
[0] * O
[1] 10 Volts low warning
[2] Live zero warning
[3] No motor warning
[4] Mains phase loss warning
[5] DC link voltage high warning
[6] DC link voltage low warning
[7] DC overvoltage warning
[8] DC undervoltage warning
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 103
3 3
