3.9.2 8-1* Ctrl. Word Settings
8-10 Control Prole
Select the interpretation of the control and status words
corresponding to the installed eldbus. Only the selections valid
for the eldbus installed in slot A are visible in the LPC display.
For guidelines in selection of [0] Frequency converter prole and
[1] PROFIdrive prole, refer to the design guide of the related
product. For more guidelines in the selection of [1] PROFIdrive
prole, [5] ODVA, and [7] CANopen DSP 402, see the installation
guide for the installed eldbus.
Option: Function:
[0] * FC prole
[1] PROFIdrive prole
[5] ODVA
Available only with VLT
®
DeviceNet MCA 104 and
VLT
®
EtherNet/IP MCA
121.
[7] CANopen DSP 402
8-13 Congurable Status Word STW
This parameter enables conguration of bits 12–15 in the status
word.
Array [16]
Option: Function:
[0] No function
[1] * Prole Default The function corresponds to the prole
default selected in parameter 8-10 Control
Prole.
[2] Alarm 68 Only Only set if alarm 68, Safe Torque O
occurs.
[3] Trip excl Alarm
68
Set if a trip occurs, unless alarm 68, Safe
Torque O is set to execute the trip.
[10] T18 DI status The bit indicates the status of terminal
18.
0 indicates that the terminal is low.
1 indicates that the terminal is high.
[11] T19 DI status The bit indicates the status of terminal
19.
0 indicates that the terminal is low.
1 indicates that the terminal is high.
[12] T27 DI status The bit indicates the status of terminal
27.
0 indicates that the terminal is low.
1 indicates that the terminal is high.
[13] T29 DI status The bit indicates the status of terminal
29.
0 indicates that the terminal is low.
1 indicates that the terminal is high.
[14] T32 DI status The bit indicates the status of terminal
32.
0 indicates that the terminal is low.
8-13 Congurable Status Word STW
This parameter enables conguration of bits 12–15 in the status
word.
Array [16]
Option: Function:
1 indicates that the terminal is high.
[15] T33 DI status The bit indicates the status of terminal
33.
0 indicates that the terminal is low.
1 indicates that the terminal is high.
[16] T37 DI status The bit indicates the status of terminal
37.
0 indicates that T37 is low (Safe Torque
O).
1 indicates that T37 is high (normal).
[20] CTW Timeout
Toggle Inverse
[21] Thermal
warning
The thermal warning turns on when the
temperature exceeds the limit in the
motor, frequency converter, brake
resistor, or thermistor.
[30] Brake fault
(IGBT)
Output is logic 1 when the brake IGBT is
short-circuited. Use this function to
protect the frequency converter if there
is a fault on the brake modules. Use the
output/relay to cut out the main voltage
from the frequency converter.
[40] Out of ref range
[60] Comparator 0 See parameter group 13-1* Comparators. If
comparator 0 is evaluated as true, the
output goes high. Otherwise, it is low.
[61] Comparator 1 See parameter group 13-1* Comparators. If
comparator 1 is evaluated as true, the
output goes high. Otherwise, it is low.
[62] Comparator 2 See parameter group 13-1* Comparators. If
comparator 2 is evaluated as true, the
output goes high. Otherwise, it is low.
[63] Comparator 3 See parameter group 13-1* Comparators. If
comparator 3 is evaluated as true, the
output goes high. Otherwise, it is low.
[64] Comparator 4 See parameter group 13-1* Comparators. If
comparator 4 is evaluated as true, the
output goes high. Otherwise, it is low.
[65] Comparator 5 See parameter group 13-1* Comparators. If
comparator 5 is evaluated as true, the
output goes high. Otherwise, it is low.
[70] Logic Rule 0 See parameter group 13-4* Logic Rules. If
logic rule 0 is evaluated as true, the
output goes high. Otherwise, it is low.
[71] Logic Rule 1 See parameter group 13-4* Logic Rules. If
logic rule 1 is evaluated as true, the
output goes high. Otherwise, it is low.
Parameter Description
VLT
®
AQUA Drive FC 202
102 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
33
