Danfoss VLT AQUA Drive FC 202 Programming Guide

13-51 SL Controller Event
Array [20]
Option: Function:
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive Mode
[91] ECB Bypass Mode
[92] ECB Test Mode
[93] Emergency Mode
[94] RS Flipop 0 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[95] RS Flipop 1 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[96] RS Flipop 2 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[97] RS Flipop 3 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[98] RS Flipop 4 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[99] RS Flipop 5 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[100] RS Flipop 6 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[101] RS Flipop 7 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[102] Verifying Flow
[103] Relay 1
[104] Relay 2
[105] Relay 3
[106] Relay 4
[107] Relay 5
[108] Relay 6
[109] Relay 7
[110] Relay 8
[111] Relay 9
[112] System On Ref
[125] Digital input x46/1
[126] Digital input x46/3
[127] Digital input x46/5
[128] Digital input x46/7
13-51 SL Controller Event
Array [20]
Option: Function:
[129] Digital input x46/9
[130] Digital input x46/11
[131] Digital input x46/13
[140] ATEX ETR cur.
warning
[141] ATEX ETR cur. alarm
[142] ATEX ETR freq.
warning
[143] ATEX ETR freq. alarm
13-52 SL Controller Action
Array [20]
Option: Function:
Select the action corresponding to the
SLC event. Actions are executed when
the corresponding event (dened in
parameter 13-51 SL Controller Event) is
evaluated as true. The following actions
are available for selection:
[0] Disabled
[1] No action
[2] Select set-up 1 Changes the active set-up
(parameter 0-10 Active Set-up) to 1.
[3] Select set-up 2 Changes the active set-up
(parameter 0-10 Active Set-up) to 2.
[4] Select set-up 3 Changes the active set-up
(parameter 0-10 Active Set-up) to 3.
[5] Select set-up 4 Changes the active set-up
(parameter 0-10 Active Set-up) to 4. If the
set-up is changed, it merges with other
set-up commands coming from either
the digital inputs or via a eldbus.
[10] Select preset ref
0
Selects preset reference 0.
[11] Select preset ref
1
Selects preset reference 1.
[12] Select preset ref
2
Selects preset reference 2.
[13] Select preset ref
3
Selects preset reference 3.
[14] Select preset ref
4
Selects preset reference 4.
[15] Select preset ref
5
Selects preset reference 5.
[16] Select preset ref
6
Selects preset reference 6.
[17] Select preset ref
7
Selects preset reference 7. If the active
preset reference is changed, it merges
with other preset reference commands
Parameter Description
VLT
®
AQUA Drive FC 202
128 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
33
