13-44 Logic Rule Boolean 3
Array [6]
Option: Function:
[90] ECB Drive Mode
[91] ECB Bypass Mode
[92] ECB Test Mode
[93] Emergency Mode
[94] RS Flipop 0
[95] RS Flipop 1
[96] RS Flipop 2
[97] RS Flipop 3
[98] RS Flipop 4
[99] RS Flipop 5
[100] RS Flipop 6 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[101] RS Flipop 7
[102] Verifying Flow
[103] Relay 1
[104] Relay 2
[105] Relay 3
[106] Relay 4
[107] Relay 5
[108] Relay 6
[109] Relay 7
[110] Relay 8
[111] Relay 9
[112] System On Ref
[125] Digital input x46/1
[126] Digital input x46/3
[127] Digital input x46/5
[128] Digital input x46/7
[129] Digital input x46/9
[130] Digital input x46/11
[131] Digital input x46/13
[140] ATEX ETR cur.
warning
[141] ATEX ETR cur. alarm
[142] ATEX ETR freq.
warning
[143] ATEX ETR freq. alarm
3.12.6 13-5* States
13-51 SL Controller Event
Array [20]
Option: Function:
Select the boolean input (true or
false) to dene the smart logic
controller event.
See parameter 13-02 Stop Event for
further descriptions of options and
their functions.
[0] False
13-51 SL Controller Event
Array [20]
Option: Function:
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 127
