13-52 SL Controller Action
Array [20]
Option: Function:
coming from either the digital inputs or
via a eldbus.
[18] Select ramp 1 Selects ramp 1.
[19] Select ramp 2 Selects ramp 2.
[22] Run Issues a start command to the frequency
converter.
[23] Run reverse Issues a start reverse command to the
frequency converter.
[24] Stop Issues a stop command to the frequency
converter.
[26] DC Brake Issues a DC stop command to the
frequency converter.
[27] Coast The frequency converter coasts
immediately. All stop commands
including the coast command stop the
SLC.
[28] Freeze output Freezes the output frequency of the
frequency converter.
[29] Start timer 0 Starts timer 0, see parameter 13-20 SL
Controller Timer for further description.
[30] Start timer 1 Starts timer 1, see parameter 13-20 SL
Controller Timer for further description.
[31] Start timer 2 Starts timer 2, see parameter 13-20 SL
Controller Timer for further description.
[32] Set digital out A
low
Any output with digital output 1
selected is low (o).
[33] Set digital out B
low
Any output with digital output 2
selected is low (o).
[34] Set digital out C
low
Any output with digital output 3
selected is low (o).
[35] Set digital out D
low
Any output with digital output 4
selected is low (o).
[36] Set digital out E
low
Any output with digital output 5
selected is low (o).
[37] Set digital out F
low
Any output with digital output 6
selected is low (o).
[38] Set digital out A
high
Any output with digital output 1
selected is high (closed).
[39] Set digital out B
high
Any output with digital output 2
selected is high (closed).
[40] Set digital out C
high
Any output with digital output 3
selected is high (closed).
[41] Set digital out D
high
Any output with digital output 4
selected is high (closed).
13-52 SL Controller Action
Array [20]
Option: Function:
[42] Set digital out E
high
Any output with digital output 5
selected is high (closed).
[43] Set digital out F
high
Any output with digital output 6
selected is high (closed).
[60] Reset Counter A Resets counter A to 0.
[61] Reset Counter B Resets counter B to 0.
[62] Counter A (up)
[63] Counter A
(down)
[64] Counter B (up)
[65] Counter B
(down)
[70] Start Timer 3 Starts timer 3, see parameter 13-20 SL
Controller Timer for further description.
[71] Start Timer 4 Starts timer 4, see parameter 13-20 SL
Controller Timer for further description.
[72] Start Timer 5 Starts timer 5, see parameter 13-20 SL
Controller Timer for further description.
[73] Start Timer 6 Starts timer 6, see parameter 13-20 SL
Controller Timer for further description.
[74] Start Timer 7 Starts timer 7, see parameter 13-20 SL
Controller Timer for further description.
[80] Sleep Mode Starts the sleep mode.
[81] Derag Starts deragging (see parameter group
29-0* Pipe Fill for further information).
[82] Reset Derag
Counter
[90] Set ECB Bypass
Mode
[91] Set ECB Drive
Mode
[100] Reset Alarms
[101] Reset Flow
Totalized
Volume Counter
[102] Reset Flow
Actual Volume
Counter
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 129
3 3
