Danfoss VLT AQUA Drive FC 202 Programming Guide

15-10 Logging Source
Array [4]
Option: Function:
[1632] Brake Energy /s
[1633] Brake Energy /2 min
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1650] External Reference
[1651] Pulse Reference
[1652] Feedback [Unit]
[1660] Digital Input
[1662] Analog Input 53
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1690] Alarm Word
[1692] Warning Word
[1694] Ext. Status Word
[3470] MCO Alarm Word 1
[3471] MCO Alarm Word 2
15-11 Logging Interval
Array [4]
Range: Function:
Size related* [ 0 - 0 ] Enter the interval in ms between each
sampling of the variables to be logged.
15-12 Trigger Event
Option: Function:
Selects the trigger event. When the
trigger event occurs, a window is
applied to freeze the log. The log
then retains a specied percentage of
samples before the occurrence of the
trigger event
(parameter 15-14 Samples Before
Trigger).
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
15-12 Trigger Event
Option: Function:
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
15-13 Logging Mode
Option: Function:
[0] * Log always Select [0] Log always for continuous logging.
[1] Log once
on trigger
Select [1] Log once on trigger to start and stop
logging conditionally using
parameter 15-12 Trigger Event and
parameter 15-14 Samples Before Trigger.
15-14 Samples Before Trigger
Range: Function:
50* [0 - 100 ] Enter the percentage of all samples to be
retained in the log before a trigger event occurs.
See also parameter 15-12 Trigger Event and
parameter 15-13 Logging Mode.
Parameter Description
VLT
®
AQUA Drive FC 202
142 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
33
