Danfoss VLT AQUA Drive FC 202

15-31 Alarm Log: Value
Array [10]
Range: Function:
0* [-32767 - 32767 ] View an extra description of the error.
This parameter is mostly used with alarm
38, internal fault.
15-32 Alarm Log: Time
Array [10]
Range: Function:
0 s* [0 - 2147483647 s] View the time when the logged event
occurred. Time is measured in s from
frequency converter start-up.
15-33 Alarm Log: Date and Time
Array [10]
Range: Function:
Size related* [ 0 - 0 ] Array parameter; Date & Time 0–9: This
parameter shows when the logged event
occurred.
15-34 Alarm Log: Setpoint
Array [10]
Range: Function:
0 ProcessCtrlUnit* [-999999.999 -
999999.999
ProcessCtrlUnit]
Array parameter; status
value 0–9. This
parameter shows the
status of the alarm:
0: Alarm inactive.
1: Alarm active.
15-35 Alarm Log: Feedback
Array [10]
Range: Function:
0 ProcessCtrlUnit* [-999999.999 - 999999.999
ProcessCtrlUnit]
15-36 Alarm Log: Current Demand
Array [10]
Range: Function:
0 %* [0 - 100 %]
15-37 Alarm Log: Process Ctrl Unit
Array [10]
Option: Function:
[0] *
[1] %
[5] PPM
[10] 1/min
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
Parameter Description
VLT
®
AQUA Drive FC 202
146 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
33
