Danfoss VLT AQUA Drive FC 202

16-55 Feedback 2 [Unit]
Range: Function:
0
ProcessCtrlUnit*
[-999999.999 -
999999.999
ProcessCtrlUnit]
View value of feedback 2, see
parameter group 20-0*
Feedback.
The unit is set in
parameter 20-12 Reference/
Feedback Unit.
16-56 Feedback 3 [Unit]
Range: Function:
0 ProcessCtrlUnit* [-999999.999 -
999999.999
ProcessCtrlUnit]
View value of
feedback 3, see
parameter group 20-0*
Feedback.
16-58 PID Output [%]
Range: Function:
0 %* [0 - 100 %] This parameter returns the frequency
converter closed-loop PID controller output
value in percent.
16-59 Adjusted Setpoint
Range: Function:
0 ProcessCtrlUnit* [-999999.999 -
999999.999
ProcessCtrlUnit]
Shows the value of
the adjusted
setpoint.
3.15.5 16-6* Inputs and Outputs
16-60 Digital Input
Range: Function:
0
N/A
*
[0 -
1023
N/A]
View the signal states from the active digital
inputs. For example, input 18 corresponds to bit
5. 0=No signal, 1=connected signal.
Bit 0 Digital input terminal 33.
Bit 1 Digital input terminal 32.
Bit 2 Digital input terminal 29.
Bit 3 Digital input terminal 27.
Bit 4 Digital input terminal 19.
Bit 5 Digital input terminal 18.
Bit 6 Digital input terminal 37.
Bit 7 Digital input GP I/O terminal
X30/4.
Bit 8 Digital input GP I/O terminal
X30/3.
Bit 9 Digital input GP I/O terminal
X30/2.
Bits 10–63 Reserved for future terminals.
Table 3.26 Digital Input Bits
16-61 Terminal 53 Switch Setting
Option: Function:
View the setting of input terminal 53.
[0] * Current
[1] Voltage
16-62 Analog Input 53
Range: Function:
0* [-20 - 20 ] View the actual value at input 53.
16-63 Terminal 54 Switch Setting
View the setting of input terminal 54.
Option: Function:
[0] * Current
[1] Voltage
16-64 Analog Input 54
Range: Function:
0* [-20 - 20 ] View the actual value at input 54.
16-65 Analog Output 42 [mA]
Range: Function:
0* [0 - 30 ] View the actual value at output 42 in mA. The
value shown reects the selection in
parameter 6-50 Terminal 42 Output.
16-66 Digital Output [bin]
Range: Function:
0* [0 - 15 ] View the binary value of all digital outputs.
16-67 Freq. Input #29 [Hz]
Range: Function:
0 N/A* [0 - 130000 N/A] View the actual frequency rate on
terminal 29.
16-68 Freq. Input #33 [Hz]
Range: Function:
0 N/A* [0 - 130000 N/A] View the actual frequency rate on
terminal 33.
16-69 Pulse Output #27 [Hz]
Range: Function:
0 N/A* [0 - 40000 N/A] View the actual value on terminal 27 in
digital output mode.
16-70 Pulse Output #29 [Hz]
Range: Function:
0 N/A* [0 - 40000 N/A] View the actual value of pulses on
terminal 29 in digital output mode.
Parameter Description
VLT
®
AQUA Drive FC 202
152 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
