20-02 Feedback 1 Source Unit
Option: Function:
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
20-03 Feedback 2 Source
Option: Function:
See parameter 20-00 Feedback 1
Source for details.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog Input X30/11
[8] Analog Input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[15] Analog Input X48/2
[99] Normal Feedback
[100] Bus Feedback 1
[101] Bus Feedback 2
[102] Bus feedback 3
[104] Sensorless Flow
[105] Sensorless Pressure
[200] Ext. Closed Loop 1
[201] Ext. Closed Loop 2
[202] Ext. Closed Loop 3
20-04 Feedback 2 Conversion
Option: Function:
See parameter 20-01 Feedback 1 Conversion for
details.
20-04 Feedback 2 Conversion
Option: Function:
[0] * Linear
[1] Square root
20-05 Feedback 2 Source Unit
See parameter 20-02 Feedback 1 Source Unit for details.
Option: Function:
[0] * Linear
20-06 Feedback 3 Source
Option: Function:
See parameter 20-00 Feedback 1
Source for details.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog Input X30/11
[8] Analog Input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[15] Analog Input X48/2
[99] Normal Feedback
[100] Bus Feedback 1
[101] Bus Feedback 2
[102] Bus feedback 3
[104] Sensorless Flow
[105] Sensorless Pressure
[200] Ext. Closed Loop 1
[201] Ext. Closed Loop 2
[202] Ext. Closed Loop 3
20-07 Feedback 3 Conversion
Option: Function:
See parameter 20-01 Feedback 1 Conversion for
details.
[0] * Linear
[1] Square root
20-08 Feedback 3 Source Unit
See parameter 20-02 Feedback 1 Source Unit for details.
Option: Function:
[0]
[1] %
[5] PPM
[10] 1/min
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 161
