Danfoss VLT AQUA Drive FC 202 Programming Guide

20-00 Feedback 1 Source
Option: Function:
NOTICE
If feedback is not used, set its
source to [0] No Function.
Parameter 20-20 Feedback Function
determines how the PID controller
uses the 3 possible feedbacks.
Up to 3 dierent feedback signals can
be used to provide the feedback signal
for the frequency converter’s PID
controller.
This parameter denes which input is
used as the source of the rst feedback
signal.
Analog input X30/11 and analog input
X30/12 refer to inputs on VLT
®
General
Purpose I/O MCB 101.
[0] No function
[1] Analog Input 53
[2] * Analog Input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog Input
X30/11
[8] Analog Input
X30/12
[9] Analog Input
X42/1
[10] Analog Input
X42/3
[11] Analog Input
X42/5
[15] Analog Input
X48/2
[99] Normal
Feedback
[100] Bus Feedback 1
[101] Bus Feedback 2
[102] Bus feedback 3
[104] Sensorless Flow Requires set-up by MCT 10 Set-up
Software with sensorless plug-in.
[105] Sensorless
Pressure
Requires set-up by MCT 10 Set-up
Software with sensorless plug-in.
[200] Ext. Closed Loop
1
[201] Ext. Closed Loop
2
[202] Ext. Closed Loop
3
20-01 Feedback 1 Conversion
This parameter allows a conversion function to be applied to
feedback 1.
[0] Linear has no eect on the feedback.
[1] Square root is commonly used when a pressure sensor is used
to provide ow feedback (( flow ∝ pressure)).
Option: Function:
[0] * Linear
[1] Square root
20-02 Feedback 1 Source Unit
Option: Function:
NOTICE
This parameter is only available when
using pressure to temperature feedback
conversion.
If option [0] Linear is selected in
parameter 20-01 Feedback 1 Conversion, the
setting of any option in
parameter 20-02 Feedback 1 Source Unit
does not matter as a conversion is 1-to-1.
This parameter determines the unit that is used
for this feedback source, before applying the
feedback conversion of parameter 20-01 Feedback
1 Conversion. This unit is not used by the PID
controller.
[0]
[1] %
[5] PPM
[10] 1/min
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
Parameter Description
VLT
®
AQUA Drive FC 202
160 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
33
