21-30 Ext. 2 Ref./Feedback Unit
Option: Function:
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
21-31 Ext. 2 Minimum Reference
Range: Function:
0 ExtPID2Unit* [ -999999.999 -
par. 21-32
ExtPID2Unit]
See parameter 21-11 Ext. 1
Minimum Reference for
details.
21-32 Ext. 2 Maximum Reference
Range: Function:
100
ExtPID2Unit*
[ par. 21-31 -
999999.999
ExtPID2Unit]
See parameter 21-12 Ext. 1
Maximum Reference for
details.
21-33 Ext. 2 Reference Source
Option: Function:
See parameter 21-13 Ext. 1 Reference
Source for details.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[29] Analog Input X48/2
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
[33] PCD Bus Reference
[35] Digital input select
21-34 Ext. 2 Feedback Source
Option: Function:
See parameter 21-14 Ext. 1 Feedback
Source for details.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog Input X30/11
21-34 Ext. 2 Feedback Source
Option: Function:
[8] Analog Input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[15] Analog Input X48/2
[99] Normal Feedback
[100] Bus Feedback 1
[101] Bus Feedback 2
[102] Bus feedback 3
[104] Sensorless Flow
[105] Sensorless Pressure
[200] Ext. Closed Loop 1
[201] Ext. Closed Loop 2
[202] Ext. Closed Loop 3
21-35 Ext. 2 Setpoint
Range: Function:
0 ExtPID2Unit* [-999999.999 -
999999.999
ExtPID2Unit]
See parameter 21-15 Ext. 1
Setpoint for details.
21-37 Ext. 2 Reference [Unit]
Range: Function:
0 ExtPID2Unit* [-999999.999 -
999999.999
ExtPID2Unit]
See parameter 21-17 Ext. 1
Reference [Unit], Ext. 1
Reference [Unit], for details.
21-38 Ext. 2 Feedback [Unit]
Range: Function:
0 ExtPID2Unit* [-999999.999 -
999999.999
ExtPID2Unit]
See parameter 21-18 Ext. 1
Feedback [Unit] for details.
21-39 Ext. 2 Output [%]
Range: Function:
0 %* [0 - 100 %] See parameter 21-19 Ext. 1 Output [%] for
details.
3.18.5 21-4* Closed Loop 2 PID
21-40 Ext. 2 Normal/Inverse Control
Option: Function:
See parameter 21-20 Ext. 1 Normal/Inverse Control
for details.
[0] * Normal
[1] Inverse
21-41 Ext. 2 Proportional Gain
Range: Function:
0.50* [0 - 10 ] See parameter 21-21 Ext. 1 Proportional Gain for
details.
Parameter Description
VLT
®
AQUA Drive FC 202
174 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
