21-59 Ext. 3 Output [%]
Range: Function:
0 %* [0 - 100 %] See parameter 21-19 Ext. 1 Output [%] for
details.
3.18.7 21-6* Closed Loop 3 PID
21-60 Ext. 3 Normal/Inverse Control
Option: Function:
See parameter 21-20 Ext. 1 Normal/Inverse Control
for details.
[0] * Normal
[1] Inverse
21-61 Ext. 3 Proportional Gain
Range: Function:
0.50* [0 - 10 ] See parameter 21-21 Ext. 1 Proportional Gain for
details.
21-62 Ext. 3 Integral Time
Range: Function:
20 s* [0.01 - 10000 s] See parameter 21-22 Ext. 1 Integral Time
for details.
21-63 Ext. 3 Dierentation Time
Range: Function:
0 s* [0 - 10 s] See parameter 21-23 Ext. 1 Dierentation Time for
details.
21-64 Ext. 3 Dif. Gain Limit
Range: Function:
5* [1 - 50 ] See parameter 21-24 Ext. 1 Dif. Gain Limit for
details.
21-66 Ext. 3 On Reference Bandwidth
Range: Function:
5 %* [0 - 200 %] Enter the on-reference bandwidth. When the
PID control error (the dierence between the
reference and the feedback) is less than the
value of this parameter, the on-reference
status bit is high.
Parameter Description
VLT
®
AQUA Drive FC 202
176 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
