Danfoss VLT AQUA Drive FC 202 Programming Guide

6. Read power consumption either by looking for
actual power in the data line in the LCP or by
viewing 1 of the following parameters:
6a Parameter 16-10 Power [kW].
Or
6b Parameter 16-11 Power [hp] in the Main
Menu.
Note the power readout.
7. Program the speeds used in:
7a Parameter 22-32 Low Speed [RPM].
7b Parameter 22-33 Low Speed [Hz].
7c Parameter 22-36 High Speed [RPM].
7d Parameter 22-37 High Speed [Hz].
8. Program the associated power values in:
8a Parameter 22-34 Low Speed Power [kW].
8b Parameter 22-35 Low Speed Power [HP].
8c Parameter 22-38 High Speed Power [kW].
8d Parameter 22-39 High Speed Power [HP].
9. Switch back with [Auto On] or [O].
22-30 No-Flow Power
Range: Function:
0 kW* [0 - 0 kW] Readout of calculated no-ow power at
actual speed. If power drops to the display
value, the frequency converter considers the
condition as a no-ow situation.
22-31 Power Correction Factor
Range: Function:
100 %
*
[1 -
400 %]
Make corrections to the calculated power in
parameter 22-30 No-Flow Power.
If no-ow is detected when it should not be
detected, decrease the setting. However, if no-
ow is not detected when it should be
detected, increase the setting to above 100%.
22-32 Low Speed [RPM]
Range: Function:
Size
related*
[ 0 - par.
22-36
RPM]
To be used if parameter 0-02 Motor Speed
Unit is set to [0] RPM (parameter not
visible if [1] Hz is selected).
Set used speed for the 50% level.
This function is used for storing values
necessary for tuning no-ow detection.
22-33 Low Speed [Hz]
Range: Function:
Size
related*
[ 0 - par.
22-37 Hz]
To be used if parameter 0-02 Motor Speed
Unit is set for [1] Hz (parameter not visible
if [0] RPM is selected).
Set used speed for the 50% level.
22-33 Low Speed [Hz]
Range: Function:
The function is used for storing values
necessary for tuning no-ow detection.
22-34 Low Speed Power [kW]
Range: Function:
Size
related*
[ 0 -
5.50
kW]
To be used if parameter 0-03 Regional
Settings is set for [0] International
(parameter not visible if [1] North America is
selected).
Set power consumption at 50% speed level.
This function is used for storing values
necessary for tuning no-ow detection.
22-35 Low Speed Power [HP]
Range: Function:
Size
related*
[ 0 -
7.50 hp]
To be used if parameter 0-03 Regional
Settings is set for [1] North America
(parameter not visible if [0] International is
selected).
Set power consumption at 50% speed level.
This function is used for storing values
necessary for tuning no-ow detection.
22-36 High Speed [RPM]
Range: Function:
Size
related*
[ 0 -
par. 4-13
RPM]
To be used if parameter 0-02 Motor Speed
Unit is set for [0] RPM (parameter not
visible if [1] Hz is selected).
Set used speed for the 85% level.
The function is used for storing values
necessary for tuning no-ow detection.
22-37 High Speed [Hz]
Range: Function:
Size
related*
[ 0 -
par. 4-14
Hz]
To be used if parameter 0-02 Motor Speed
Unit is set for [1] Hz (parameter not visible
if [0] RPM is selected).
Set used speed for the 85% level.
The function is used for storing values
necessary for tuning no-ow detection.
22-38 High Speed Power [kW]
Range: Function:
Size
related*
[ 0 -
5.50
kW]
To be used, if parameter 0-03 Regional
Settings is set for [0] International
(parameter not visible if [1] North America is
selected).
Set power consumption at 85% speed level.
This function is used for storing values
necessary for tuning no-ow detection.
Parameter Description
VLT
®
AQUA Drive FC 202
182 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
