24-02 Emergency Mode Unit
Option: Function:
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
24-03 Emergency Mode Min Reference
Range: Function:
Size
related*
[ -999999.999
- par. 24-04
FireModeUnit]
Minimum value for the reference/
setpoint (limiting the sum of value in
parameter 24-05 Emergency Mode
Preset Reference and value of signal on
input selected in
parameter 24-06 Emergency Mode
Reference Source).
If running in open loop when
emergency mode is active, the unit is
selected by the setting of
parameter 0-02 Motor Speed Unit. For
closed loop, select the unit in
parameter 24-02 Emergency Mode Unit.
24-04 Emergency Mode Max Reference
Range: Function:
Size
related*
[ par. 24-03
- 999999.999
FireMo-
deUnit]
Maximum value for the reference/
setpoint (limiting the sum of value in
parameter 24-05 Emergency Mode Preset
Reference and value of signal on input
selected in parameter 24-06 Emergency
Mode Reference Source).
If running in open loop when
emergency mode is active, the unit is
selected by the setting of
parameter 0-02 Motor Speed Unit. For
closed loop, select the unit in
parameter 24-02 Emergency Mode Unit.
24-05 Emergency Mode Preset Reference
Range: Function:
0 %* [-100 -
100 %]
Enter the required preset reference/setpoint as a
percentage of the value in
parameter 24-04 Emergency Mode Max Reference.
The set value is added to the value represented
by the signal on the analog input selected in
parameter 24-06 Emergency Mode Reference
Source.
Parameter Description
VLT
®
AQUA Drive FC 202
204 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
