35-25 Term. X48/7 Temp. Monitor
This parameter gives the possibility of enabling or disabling the
temperature monitor for terminal X48/7. The temperature limits
can be set in parameter 35-26 Term. X48/7 Low Temp. Limit and
parameter 35-27 Term. X48/7 High Temp. Limit.
Option: Function:
[0] * Disabled
[1] Enabled
35-26 Term. X48/7 Low Temp. Limit
Range: Function:
Size related* [ -50 - par.
35-27 ]
Enter the minimum temperature
reading that is expected for
normal operation of the
temperature sensor at terminal
X48/7.
35-27 Term. X48/7 High Temp. Limit
Range: Function:
Size related* [ par. 35-26 -
204 ]
Enter the maximum temperature
reading that is expected for
normal operation of the
temperature sensor at terminal
X48/7.
3.28.4 35-3* Temp. Input X48/10 (MCB 114)
35-34 Term. X48/10 Filter Time Constant
Range: Function:
0.005 s* [0.005 - 10
s]
Enter the lter time constant. This is a
rst-order digital low-pass lter time
constant for suppressing electrical noise
in terminal X48/10. A high time constant
value improves dampening, but also
increases the time delay through the
lter.
35-35 Term. X48/10 Temp. Monitor
This parameter gives the possibility of enabling or disabling the
temperature monitor for terminal X48/10. The temperature limits
can be set in parameter 35-36 Term. X48/10 Low Temp. Limit/
parameter 35-37 Term. X48/10 High Temp. Limit.
Option: Function:
[0] * Disabled
[1] Enabled
35-36 Term. X48/10 Low Temp. Limit
Enter the minimum temperature reading that is expected for
normal operation of the temperature sensor at terminal X48/10.
Range: Function:
Size related* [ -50 - par. 35-37 ]
35-37 Term. X48/10 High Temp. Limit
Enter the maximum temperature reading that is expected for
normal operation of the temperature sensor at terminal X48/10.
Range: Function:
Size related* [ par. 35-36 - 204 ]
3.28.5 35-4* Analog Input X48/2 (MCB 114)
35-42 Term. X48/2 Low Current
Range: Function:
4 mA* [ 0 - par.
35-43 mA]
Enter the current (mA) that corresponds to
the low reference value, set in
parameter 35-44 Term. X48/2 Low Ref./Feedb.
Value. Set the value at >2 mA to activate the
live-zero timeout function in
parameter 6-01 Live Zero Timeout Function.
35-43 Term. X48/2 High Current
Range: Function:
20 mA* [ par. 35-42 -
20 mA]
Enter the current (mA) that corresponds
to the high reference value (set in
parameter 35-45 Term. X48/2 High Ref./
Feedb. Value).
35-44 Term. X48/2 Low Ref./Feedb. Value
Range: Function:
0 ReferenceFeed-
backUnit*
[-999999.999 -
999999.999
ReferenceFeed-
backUnit]
Enter the reference or
feedback value (in RPM,
Hz, bar, and so on) that
corresponds to the voltage
or current set in
parameter 35-42 Term.
X48/2 Low Current.
35-45 Term. X48/2 High Ref./Feedb. Value
Range: Function:
100 Reference-
FeedbackUnit*
[-999999.999 -
999999.999
ReferenceFeed-
backUnit]
Enter the reference or
feedback value (in RPM,
Hz, bar, and so on) that
corresponds to the voltage
or current set in
parameter 35-43 Term.
X48/2 High Current.
35-46 Term. X48/2 Filter Time Constant
Range: Function:
0.005 s* [0.005 - 10
s]
Enter the lter time constant. This is a
rst-order digital low-pass lter time
constant for suppressing electrical noise
in terminal X48/2. A high time constant
value improves dampening, but also
increases the time delay through the
lter.
Parameter Description
VLT
®
AQUA Drive FC 202
246 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
