0-20 Display Line 1.1 Small
Option: Function:
[1676] Analog In
X30/12
Actual value of the signal on input
X30/12 (VLT
®
General Purpose I/O MCB
101, optional).
[1677] Analog Out
X30/8 [mA]
Actual value at output X30/8 (VLT
®
General Purpose I/O MCB 101, optional).
Use parameter 6-60 Terminal X30/8
Output to select the variable to be
shown.
[1678] Analog Out
X45/1 [mA]
[1679] Analog Out
X45/3 [mA]
[1680] Fieldbus CTW
1
Control word (CTW) received from the
eldbus.
[1682] Fieldbus REF 1 Main reference value sent with control
word via the serial communications
network, for example, from the BMS,
PLC, or another controller.
[1684] Comm. Option
STW
Extended eldbus communication
option status word.
[1685] FC Port CTW 1 Control word (CTW) received from the
eldbus.
[1686] FC Port REF 1 Status word (STW) sent to the eldbus.
[1690] Alarm Word One or more alarms in hex code (used
for serial communication).
[1691] Alarm Word 2 One or more alarms in hex code (used
for serial communication).
[1692] Warning Word One or more warnings in hex code
(used for serial communication).
[1693] Warning Word
2
One or more warnings in hex code
(used for serial communication).
[1694] Ext. Status
Word
One or more status conditions in hex
code (used for serial communication).
[3401] PCD 1 Write to
MCO
[3402] PCD 2 Write to
MCO
[3403] PCD 3 Write to
MCO
[3404] PCD 4 Write to
MCO
[3405] PCD 5 Write to
MCO
[3406] PCD 6 Write to
MCO
[3407] PCD 7 Write to
MCO
[3408] PCD 8 Write to
MCO
0-20 Display Line 1.1 Small
Option: Function:
[3409] PCD 9 Write to
MCO
[3410] PCD 10 Write
to MCO
[3421] PCD 1 Read
from MCO
[3422] PCD 2 Read
from MCO
[3423] PCD 3 Read
from MCO
[3424] PCD 4 Read
from MCO
[3425] PCD 5 Read
from MCO
[3426] PCD 6 Read
from MCO
[3427] PCD 7 Read
from MCO
[3428] PCD 8 Read
from MCO
[3429] PCD 9 Read
from MCO
[3430] PCD 10 Read
from MCO
[3440] Digital Inputs
[3441] Digital Outputs
[3450] Actual Position
[3451] Commanded
Position
[3452] Actual Master
Position
[3453] Slave Index
Position
[3454] Master Index
Position
[3455] Curve Position
[3456] Track Error
[3457] Synchronizing
Error
[3458] Actual Velocity
[3459] Actual Master
Velocity
[3460] Synchronizing
Status
[3461] Axis Status
[3462] Program Status
[3470] MCO Alarm
Word 1
[3471] MCO Alarm
Word 2
[9913] Idle time
Parameter Description
VLT
®
AQUA Drive FC 202
32 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
