0-20 Display Line 1.1 Small
Option: Function:
[1613] Frequency Motor frequency, that is the output
frequency from the frequency converter
in Hz.
[1614] Motor Current Phase current of the motor measured as
eective value.
[1615] Frequency [%] Motor frequency, that is the output
frequency from the frequency converter
in percent.
[1616] Torque [Nm] Present motor load as a percentage of
the rated motor torque.
[1617]
*
Speed [RPM] Speed in RPM (revolutions per minute),
that is the motor shaft speed in closed
loop based on the entered motor
nameplate data, the output frequency,
and the load on the frequency
converter.
[1618] Motor Thermal Thermal load on the motor calculated
by the ETR function. See also parameter
group 1-9* Motor Temperature.
[1619] KTY sensor
temperature
[1620] Motor Angle
[1622] Torque [%] Shows the actual torque produced in
percentage.
[1625] Torque [Nm]
High
[1630] DC Link
Voltage
DC-link voltage in the frequency
converter.
[1632] Brake Energy /s Present brake power transferred to an
external brake resistor.
Shows an instant value.
[1633] Brake
Energy /2 min
Brake power transferred to an external
brake resistor. The average power is
calculated continuously for the most
recent 120 s.
[1634] Heatsink Temp. Present heat sink temperature of the
frequency converter. The cutout limit is
95 ±5 °C. Cutting back in occurs at 70
±5 °C.
[1635] Inverter
Thermal
Percentage load of the inverters.
[1636] Inv. Nom.
Current
Nominal current of the frequency
converter.
[1637] Inv. Max.
Current
Maximum current of the frequency
converter.
[1638] SL Controller
State
State of the event executed by the
control.
[1639] Control Card
Temp.
Temperature of the control card.
0-20 Display Line 1.1 Small
Option: Function:
[1650] External
Reference
Sum of the external reference as a
percentage, that is the sum of analog,
pulse, and bus.
[1651] Pulse
Reference
[1652] Feedback [Unit] Signal value in units from the
programmed digital inputs.
[1653] Digi Pot
Reference
View the contribution of the digital
potentiometer to the actual reference
feedback.
[1660] Digital Input Shows the status of the digital inputs.
Signal low=0, signal high=1.
Regarding order, see
parameter 16-60 Digital Input. Bit 0 is at
the extreme right.
[1661] Terminal 53
Switch Setting
Setting of input terminal 53. Current=0,
voltage=1.
[1662] Analog Input
53
Actual value at input 53 either as a
reference or protection value.
[1663] Terminal 54
Switch Setting
Setting of input terminal 54. Current=0,
voltage=1.
[1664] Analog Input
54
Actual value at input 54 either as
reference or protection value.
[1665] Analog Output
42 [mA]
Actual value at output 42 in mA. Use
parameter 6-50 Terminal 42 Output to
select the variable to be show in output
42.
[1666] Digital Output
[bin]
Binary value of all digital outputs.
[1667] Freq. Input #29
[Hz]
Actual value of the frequency applied at
terminal 29 as a pulse input.
[1668] Freq. Input #33
[Hz]
Actual value of the frequency applied at
terminal 33 as a pulse input.
[1669] Pulse Output
#27 [Hz]
Actual value of pulses applied to
terminal 27 in digital output mode.
[1670] Pulse Output
#29 [Hz]
Actual value of pulses applied to
terminal 29 in digital output mode.
[1671] Relay Output
[bin]
View the setting of all relays.
[1672] Counter A View the present value of counter A.
[1673] Counter B View the present value of counter B.
[1674] Prec. Stop
Counter
[1675] Analog In
X30/11
Actual value of the signal on input
X30/11 (VLT
®
General Purpose I/O MCB
101, optional).
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 31
3 3
