Danfoss VLT AQUA Drive FC 202 Programming Guide

6-21 Terminal 54 High Voltage
Range: Function:
10 V* [ par. 6-20
- 10 V]
Enter the high voltage value. This analog
input scaling value should correspond to the
high reference feedback value set in
parameter 6-25 Terminal 54 High Ref./Feedb.
Value.
6-22 Terminal 54 Low Current
Range: Function:
4 mA* [ 0 -
par. 6-23
mA]
Enter the low current value. This reference
signal should correspond to the low reference
feedback value set in parameter 6-24 Terminal
54 Low Ref./Feedb. Value. Set the value at
>2 mA to activate the live zero timeout
function in parameter 6-01 Live Zero Timeout
Function.
6-23 Terminal 54 High Current
Range: Function:
20 mA* [ par. 6-22
- 20 mA]
Enter the high current value
corresponding to the high reference
feedback value set in
parameter 6-25 Terminal 54 High Ref./Feedb.
Value.
6-24 Terminal 54 Low Ref./Feedb. Value
Range: Function:
0 ReferenceFeed-
backUnit*
[-999999.999 -
999999.999
ReferenceFeed-
backUnit]
Enter the analog input
scaling value that
corresponds to the low
voltage/low current value
set in
parameter 6-20 Terminal 54
Low Voltage and
parameter 6-22 Terminal 54
Low Current.
6-25 Terminal 54 High Ref./Feedb. Value
Range: Function:
100 Reference-
FeedbackUnit*
[-999999.999 -
999999.999
ReferenceFeed-
backUnit]
Enter the analog input
scaling value that
corresponds to the high
voltage/high current value
set in
parameter 6-21 Terminal 54
High Voltage and
parameter 6-23 Terminal 54
High Current.
6-26 Terminal 54 Filter Time Constant
Range: Function:
0.005 s* [0.005 - 10
s]
NOTICE
This parameter cannot be adjusted
while the motor is running.
Enter the lter time constant. This is a
rst-order digital low-pass lter time
constant for suppressing electrical noise in
terminal 54. Increasing the value improves
dampening but also increases the time
delay through the lter.
6-27 Terminal 54 Live Zero
Option: Function:
[0] Disabled
[1] * Enabled This parameter makes it possible to disable the
live zero monitoring. For example, this is used if
the analog outputs are used as part of a
decentral I/O system (for example when not part
of any control functions related to the frequency
converter, but feeding an external control system
with data).
3.8.4 6-3* Analog Input X30/11
Parameter group for conguring the scale and limits for
analog input 3 (X30/11) placed on VLT
®
General Purpose
I/O MCB 101.
6-30 Terminal X30/11 Low Voltage
Range: Function:
0.07 V* [ 0 - par.
6-31 V]
Sets the analog input scaling value to
correspond to the low reference feedback
value (set in parameter 6-34 Term. X30/11
Low Ref./Feedb. Value).
6-31 Terminal X30/11 High Voltage
Range: Function:
10 V* [ par. 6-30 -
10 V]
Sets the analog input scaling value to
correspond to the high reference feedback
value (set in parameter 6-35 Term. X30/11
High Ref./Feedb. Value).
6-34 Term. X30/11 Low Ref./Feedb. Value
Range: Function:
0 ReferenceFeed-
backUnit*
[-999999.999 -
999999.999
ReferenceFeed-
backUnit]
Sets the analog input
scaling value to
correspond to the low
voltage value (set in
parameter 6-30 Terminal
X30/11 Low Voltage).
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 93
3 3
