Danfoss VLT HVAC Basic Drive FC 101

130BC201.10
Figure 5.13 I3 Frame
IP54 380–480 V 75–100 hp [5.5–7.5 kW]
1
RS-485
2 Line in
3 Ground
4 Wire clamps
5 Motor
6 UDC
7 Relays
8 I/O
Table 5.12 Legend to Figure 5.13
130BD011.10
Figure 5.14 I4 Frame
IP54 380–480 V 1–5 hp [0.75–4.0 kW]
1
RS-485
2 Line in
3 Ground
4 Wire clamps
5 Motor
6 UDC
7 Relays
8 I/O
Table 5.13 Legend to Figure 5.14
How to Install Design Guide
