Manual Datafox Evo 4.3 Page 111 Date: 27.12.2017 V 04.03.09.XX
Statusmeldungen der Zutrittskotrolle
display
Assigned status message
120#
digital output 7 is low (Off).
121#
digital output 7 is HIGH.(On).
122#
digital output 7 is for the time ELAPSE, HIGH.
123#
digital output 8 is low (Off).
124#
digital output 8 is HIGH.(On).
125#
digital output 8 is for the time ELAPSE, HIGH.
126#
digital output 9 is low (Off).
127#
digital output 9 is HIGH.(On).
128#
digital output 9 is for the time ELAPSE, HIGH.
129#
digital output 10 is low (Off).
130#
digital output 10 is HIGH.(On).
131#
digital output 10 is for the time ELAPSE, HIGH.
132#
digital output 11 is low (Off).
133#
digital output 11 is HIGH.(On).
134#
digital output 11 is for the time ELAPSE, HIGH.
135#
digital output 12 is low (Off).
136#
digital output 12 is HIGH.(On).
137#
digital output 12 is for the time ELAPSE, HIGH.
138#
digital output 13 is low (Off).
139#
digital output 13 is HIGH.(On).
140#
digital output 13 is for the time ELAPSE, HIGH.
141#
digital output 14 is low (Off).
142#
digital output 14 is HIGH.(On).
143#
digital output 14 is for the time ELAPSE, HIGH.
141#
digital output 15 is low (Off).
142#
digital output 15 is HIGH.(On).
143#
digital output 15 is for the time ELAPSE, HIGH.
144#
digital output 16 is low (Off).
145#
digital output 16 is HIGH.(On).
146#
digital output 16 is for the time ELAPSE, HIGH.
160#
digital input 7 is Low
161#
digital input 7 is HIGH
162#
digital input 8 is Low
163#
digital input 8 is HIGH
164#
digital input 9 is Low
165#
digital input 9 is HIGH
166#
digital input 10 is Low
167#
digital input 10 is HIGH
168#
digital input 11 is Low
169#
digital input 11 is HIGH
170#
digital input 12 isLow
171#
digital input 12 is HIGH
_____
____continuously until:
210#
digital input 32 is Low
211#
digital input 32 is HIGH
# for new devices hardware version 4
