5.5.2. Powersupply of the EVO 4.3
5.5.2.1. Powersupply
The delivery power supply have 12V DC / 18 W.
The terminal itself can be supplied with a supply voltage of 24 V DC.
The power supply:
5.5.2.2. Power via POE
An option for the power is a POE-modul (Art. Nr: 115117).
This POE-modul supporter 2 standards.
PoE-Standard
power
useable power
PoE
IEEE 802.3af
15,4 Watt
12,95 Watt
PoE+
IEEE 802.3at
25,4 Watt
21,90 Watt
If power is supplied via POE, an external access-reader can also be supplied via the access control
plug.
Reverse polarity protected connector
