Manual Datafox Evo 4.3 Page 68 Date: 27.12.2017 V 04.03.09.XX
ID of the room. All other tables refer to this data line via this number, if neces-
sary.
Reference to the identification table. Labels the access authorized group. All
cards of this group have access to this room.
The time model in which authorized persons get access. (0 = not used)
The time model for which entering an additional PIN is not necessary (at peak
times etc.).
Table Location (defines which card groups get access to which room at which time)
ID of the time model. All other tables refer to this data line via this number, if
necessary.
Indicates the weekdays on which the following period of time should be applied
(form: 7 digits at most 1-7 e.g. 134567 = Monday, Wednesday till Sunday)
The start point for the period of time. (form: 24h HH:MM)
The end point for the period of time.
Table Time (grouping of single time zones (weekday from to) as a time model number)
Module (door module or master) where the digital input is.
Number of the digital input on the module.
Reference to the action that should be carried out (e.g. switch relay).
The time model which indicates when the digital input is checked. (0 = not
used).
Table Event (assigning an action to a signal at the digital input)
Action number, it can occur several times due to several actions that have to be
worked through.
Module (door module or master) on which an output(relay) is switched.
Indicates the number of the output on the module.
The duration of the switching of the relay (0 = permanently). Unit 200 ms
The time model indicates when the output may be switched. (0 = not used)
Table Action (list of all workable actions in the access control system; an action group, i.e. all ac-
tions with the same action number, can switch several relays)
