5.7.4.1. Connecting of the EVO-access reader examples
Cable plan for one door, 1 Relay in the EVO 4.3:
Reader Tabelle, for this example:
ID
ZM / Bus-ID
TM (Busadresse)
RefLocation
RefAction
PinGeneral
Beschreibungstext
1
1
010
1
1
0
Reader on RS485 Modulplace 1 = Bus ID 1
4
1
320
0
1
0
access-Box V4 (Masterdevice)
Wire plan for one access reader EVO:
TCP / IP (LAN)
M1
SIM
12VDC
USB
GPRS
GPS
RS232
M7
LAN
M8
485-A
485-B
12V 
GND
M3
M2
DGND
D IN1
Relais
ZK
485-A
485-B
HK
Variante mit RS485 Haupt-
kommunikation
RS 485 ZK Bus-ID 1
Bus Nr. 1
Bus Nr. 1
Türöffner Relais 1 der ZK-Box
12V vom Master
+ - max. 30V; 2A
Power supply for door opener
Bus Nr. 1
EVO-access reader
Connector 4 pole
for Access Bus
connector 5 pole
for digital in and
out
