6.1. communication modules
LAN (TCP / IP)
Width 20mm
10 / 100Mbit, IPv4, IPv6
WLAN
Width 20mm
Standard 802.11.b/g, encryption WEP, WPA2 802 / 11i
GPRS
Width 40mm
GPRS class 10, quad band, mini-SIM socket
RS485
Width 20mm
RS485 connections, up to 30 participants
6.2. access modules
RS485
Width 20mm
RS485 connection for the access reader, relay modules, ... power
supply from 1 external reader when using Datafox power supplies with
12V
Access Control-IO
Width 20mm
1 relay changeover, 42 V AC, DC 60 V, 2 A, max. 60 W; 1 digital input
for monitoring door, ...
6.3. Module digital in and out
Digital inputs
20mm
4 x digital input, functional insulation 230V, depending on the device
type, up to 250kHz, Low 0.0 ... 1.0 V; High 3,5 ... 30,0V
Digital outputs relay
20mm
1 x NO contact, 1 x change-over contact, 30 V AC, 30 V DC, 2 A, max.
60 W
Digital outputs Open Coll.
20mm
4 x open collector output, 2A, 30V (in preparation)
Analog inputs voltage
20mm
4 x input, 15-bit resolution, accuracy ± 2%, range 0-10 V, other ranges
and functional insulation 230 V on request
6.4. Modules miscellaneous
RS232-Modul
Width 20mm
RS232 interface, with MiniDIN connector or spring terminal
5V-output max. 0,5A, with USB supply max. 100mA.
GPS
Width 20mm
50 Channels, GPS L1 frequency C/A, GALILEO Open Service L1
Micro-SD Card
Width 20mm
Micro-SD Card max. 2GB, depending on device accessible from
outside the device
Mobil-Box-Modul
Width 40mm
Central connector for power supply, (8-30V DC), 1 relay, 2 digital
inputs and connection for Mobile-Dockingstation with Timeboy
Acceleration sensor
Width 20mm
3D acceleration sensor in preparation
7. FAQ
An extensive collection of FAQs can be found on our homepage:
http://www.datafox.de/faq-de.html
