5.4. Installation of the EVO 4.3 Terminal
The wall mounting takes place by means of a wall bracket. This is attached to the wall via 3 attach-
ment points.
Fixed scew
The terminal is
mounted at the to.
On the down site
kann you fixed the
terminal ith a scew.
The attachment points are
compatible to the PZE-
Maser.
Torx T8
