Manual Datafox Evo 4.3 Page 90 Date: 27.12.2017 V 04.03.09.XX
5.7.6.1. Installation Variants
A Door without a Separate Reader
The EVO 4.3 is access scanner, access master and door-opener at the same time. This solution
should only be used in protected areas so that the door opening relay cannot be manipulated.
.
RS232/485
TCP/IP
GSM/GPRS
WLAN
Caution:
The installation and connection of the TMR33 module may only be carried out by a qual-
ified specialist. Avoid switching the connecting terminal (reverse polarity).
