4. System Requirements / Hardware
4.1. System Structure
The system consists of the Datafox device, the DatafoxStudioIV, the communication DLL and a
software for processing the generated data.
4.2. Requirements for Operating Datafox Devices
In order to operate the Datafox device, you need a 230 V power connection for the Datafox power
supply. Depending on the main communication set, you need a corresponding transfer medium or
connection cable.
Main communication:
 USB > one standard USB-A toUSB-mirco Cable (see the chapter connection USB).
 RS485 > a transmission path in accordance with the EIA-485 standard (see Connection
RS485).
 GSM/GPRS > a distortion-free mobile connection (see Connection GSM).
 WLAN WiFi> a distortion-free channel to an access point (802.11 b/g) within reach (see
Connection WLAN).
 at least one standard Ethernet cable, no „cross over“ (see Connection TCP)
 HTTP(internet) via LAN > TCP/IP connection with free internet access. The data are sent
to a server.

Note:
With increasing demands on transfer rate and interference immunity, the demands
on the transmission path increase as well with regard to quality (interference immuni-
ty).
Setup
Create setup
Save setup
Transfer setup to device
Software for processing the generated data
DatafoxStudioIV
Communication- DLL
